LF08E – Pressure Switch for Water Purifier
0.05~0.35MPa
For Application Advice
Please Call
Please Call
- 01684 566163
This product is specially designed for water purifiers, which can replace traditional high-low pressure switches. It has a more sensitive action and is used for a wider range of applications.
| Media | Air, Water |
| Pressure range | 0.05~0.35MPa |
| Performance | One or two pressure settings |
| Proof pressure | 1.2MPa |
| Burst pressure | 3.2MPa |
| Terminal | 6.35 x 0.8mm or 4.8 x 0.8mm tabs |
| Temperature range | -20°C~120°C |
| Circuitry | SPST (NC or NO) |
| Electric rating | 250VAC, 3A |
