Main Features:

• Push-Pull self-latching
• 2 ~ 32 contacts
• Solder cup contacts
• Touch & scoop proof
• High density for space saving
• Multiple key options to avoid cross-mating
• Temp. range: -55°C ~ 250°C
• Cable size: ø1.5 ~ ø10.5 mm
• Outer shell & back nut: copper alloy plating Cr
• Insulator: Polyetheretherketone UL94-0 (peek)
• Contact: Copper alloy plating Ni
• IP rating IP67 (when mated)
• Working temperature: -55^oC ~ 200^oC
• Mating cycles: >3,000 cycles
